Loan Default Predictive Modeling

No description has been provided for this image This project is my solution for Task 3 of the J.P. Morgan Quantitative Researcher job simulation on Forage. The task is to train a predictive model on a dataset of loan borrowers and determine the probability that a borrower will default. This probability will be used to calculate the expected loss on a loan. The models below were trained using pandas, numpy, and scikit-learn, with plotly used to visualize the dataset.
In [2]:
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
import plotly.express as px
import plotly.express as px
import plotly.graph_objects as go
from plotly.subplots import make_subplots

from sklearn.model_selection import train_test_split
from sklearn.model_selection import cross_val_score
from sklearn.tree import DecisionTreeClassifier
from sklearn.naive_bayes import GaussianNB
from sklearn.neural_network import MLPClassifier
from sklearn.ensemble import GradientBoostingClassifier, RandomForestClassifier
from sklearn.neighbors import KNeighborsClassifier
from sklearn.svm import SVC

from datetime import datetime
from tabulate import tabulate

This code block loads the dataset into a Pandas dataframe. The models will predict which category each borrower belongs to: 1 for those who default on their loan and 0 for those who do not. Therefore, I will convert the target variable (default) to a category datatype. The remaining columns are the feature values, the inputs for the predictive models. As customer_id is unique for each borrower, I expect it has little correlation with a borrower's likelihood to default. I will visualize the other features to understand how the model makes its predictions.

In [4]:
loan_df = pd.read_csv('Loan_Data.csv')
loan_df['default'] = loan_df['default'].astype('category')
loan_df.head()
Out[4]:
customer_id credit_lines_outstanding loan_amt_outstanding total_debt_outstanding income years_employed fico_score default
0 8153374 0 5221.545193 3915.471226 78039.38546 5 605 0
1 7442532 5 1958.928726 8228.752520 26648.43525 2 572 1
2 2256073 0 3363.009259 2027.830850 65866.71246 4 602 0
3 4885975 0 4766.648001 2501.730397 74356.88347 5 612 0
4 4700614 1 1345.827718 1768.826187 23448.32631 6 631 0

I will use Pandas' describe function to calculate the summary statistics for all numerical features (excluding customer_id).

In [6]:
loan_df.iloc[:, 1:].describe()
Out[6]:
credit_lines_outstanding loan_amt_outstanding total_debt_outstanding income years_employed fico_score
count 10000.000000 10000.000000 10000.000000 10000.000000 10000.000000 10000.000000
mean 1.461200 4159.677034 8718.916797 70039.901401 4.552800 637.557700
std 1.743846 1421.399078 6627.164762 20072.214143 1.566862 60.657906
min 0.000000 46.783973 31.652732 1000.000000 0.000000 408.000000
25% 0.000000 3154.235371 4199.836020 56539.867903 3.000000 597.000000
50% 1.000000 4052.377228 6732.407217 70085.826330 5.000000 638.000000
75% 2.000000 5052.898103 11272.263740 83429.166133 6.000000 679.000000
max 5.000000 10750.677810 43688.784100 148412.180500 10.000000 850.000000

The credit_lines_outstanding feature measures how many lines of credit a borrower has opened and not repaid. On average, each borrower has 1-2 lines of credit, though some have as many as 5. Using a histogram, I visualized the percentage of borrowers with x lines of credit for each target class. It is clear to see that more outstanding lines of credit correlates with a greater probability of default. Over 90% of borrowers with 4 or more credit lines outstanding defaulted on their loan.

In [8]:
fig = px.histogram(
    loan_df,
    x = 'credit_lines_outstanding',
    color = 'default',
    title = 'Default Percentages vs Total Credit Lines',
    barmode = 'group',
    histnorm = 'percent',
    template = 'plotly_white',
    category_orders = {'default': [0, 1]}
)

fig.show()

The documentation does not clearly distinguish the difference between loan_amt_outstanding and total_debt_outstanding, but my assumption is that loan_amt_outstanding refers to unpaid principal and total_debt_outstanding is any additional fees and accrued interest.

The boxplots below compare outstanding loan amounts and total debt outstanding between borrowers who defaulted and those who repaid their loans. The medians and quartiles of the two classes' outstanding loan amounts are very similar, and the difference between the two distributions does not appear to be statistically significant. In contrast, the total debt outstanding boxplot contrasts more sharply; borrowers who defaulted tended to accumulate much more debt. Notably, the top 75% of borrowers who defaulted owed more debt than the bottom 75% of repayers.

In [10]:
#Creates 1 row of 2 subplots for Outstanding Loan Amount and Total Debt Outstanding
fig = make_subplots(
    rows=1, cols=2,
    subplot_titles=("Oustanding Loan Amount", "Total Debt Oustanding"),
)

#These are the two variables I will
var = ['loan_amt_outstanding', 'total_debt_outstanding']
marker_colors = ['blue', 'red']

#This for-loop creates four boxplot traces on 2 subplots. One for each target class' loan_amt_outstanding and total_debt_outstanding features
#Target values are 0 (did not default) and 1 (defaulted on loan)
for target in range(2):
    #Tracks which subplot the current trace should be plotted on
    for col in range(2):
        fig.add_trace(
            go.Box(
                x = loan_df[loan_df['default'] == target]['default'],
                y = loan_df[loan_df['default'] == target][var[col]],
                marker_color = marker_colors[target]
            ),
            row = 1,
            col = col + 1
        )

#Applies the template to both plots
fig.update_layout(template = "plotly_white", showlegend = False)
fig.show()
In [11]:
fig = px.histogram(
    loan_df,
    x = 'total_debt_outstanding',
    color = 'default',
    title = 'Loan Borrowers Outstanding Debt by Default Group',
    barmode = 'overlay',
    histnorm = 'percent',
    template = 'plotly_white'
)

fig.show()

The income distributions for defaulters and repayers are very similar. Both distributions appear normal, with a mean around $70k. A borrower's debt relative to their income is likely more useful in predicting default risk.

In [13]:
fig = px.histogram(
    loan_df,
    x = 'income',
    color = 'default',
    title = 'Loan Borrower Income by Default Group',
    barmode = 'overlay',
    histnorm = 'percent',
    template = 'plotly_white'
)

fig.show()

While income has low correlation with probability of default, debt relative to income appears to be highly correlated. When a borrower owes about 20% of their income as outstanding debt, they become much more likely to default. JP Morgan Chase could use this information to predict a borrower's likelihood of default over time; a borrower whose debt begins to reach the 20% of income threshold should be flagged as high risk of default.

In [15]:
fig = go.Figure()

#Plots debt vs income scatterplot for borrowers who did not default (0)
fig.add_trace(go.Scatter(
    x = loan_df[loan_df['default'] == 0]['income'],
    y = loan_df[loan_df['default'] == 0]['total_debt_outstanding'],
    mode = 'markers',
    marker_color = 'blue',
    name = '0',
    opacity = 0.5,
    zorder = 0
))

#Plots debt vs income scatterplot for borrowers who did default (1)
fig.add_trace(go.Scatter(
    x = loan_df[loan_df['default'] == 1]['income'],
    y = loan_df[loan_df['default'] == 1]['total_debt_outstanding'],
    mode = 'markers',
    marker_color = 'red',
    name = '1',
    opacity = 0.5,
    zorder = 0
))

#Based on the data, I estimate the decision boundary is y=0.2x
#This code uses numpy to generate 20 points for that line
x_line = np.linspace(0, 150000, num = 20)
y_line = x_line * 0.20

#Plots the estimated decision boundary as a line
fig.add_trace(go.Scatter(
    x=x_line,
    y=y_line,
    mode='lines',
    name = 'y=0.2x',
    line=dict(color='black', width=2),
    zorder=1
))

#Applies template and adds a title
fig.update_layout(template = "plotly_white", title = 'Outstanding Debt vs Income')
fig.show()

The value for years_employed ranges from 0 to 10, and the average value is roughly 4.5 years. To determine the impact of years_employed on default probability, I graphed the proportion of borrowers who defaulted by years employed. As years employed increases, this proportion decreases. I will create a pivot table to understand this trend.

In [17]:
employed_default_prop = loan_df.groupby('years_employed')['default'].value_counts(normalize = True).reset_index()

fig = px.bar(
    employed_default_prop,
    x = 'years_employed',
    y = 'proportion',
    color = 'default',
    title = 'Default Proportions by Years Employed',
    template = 'plotly_white',
    category_orders = {'default': [0, 1]}
)

fig.show()

There are two key trends in the pivot table when comparing the two groups. On average, borrowers who default have more credit lines outstanding and much more total debt outstanding. This confirms the insights from the other visualizations. Additionally, borrowers who repaid their loans had higher average fico_score values, but this trend is less reliable as years_employed increases.

In [19]:
value_cols = ['credit_lines_outstanding', 'loan_amt_outstanding', 'total_debt_outstanding', 'income', 'fico_score']

years_employed_default_df = pd.pivot_table(
    loan_df,
    index = ['default', 'years_employed'],
    values = value_cols,
    observed = False
).reset_index()

years_employed_default_df.sort_values(by = ['years_employed', 'default'])
Out[19]:
default years_employed credit_lines_outstanding fico_score income loan_amt_outstanding total_debt_outstanding
0 0 0 0.500000 608.800000 63938.530390 4483.093431 6667.892335
11 1 0 3.636364 580.818182 69312.865828 4739.948908 17589.244442
1 0 1 0.535211 640.323944 71336.091945 4648.299663 6370.618752
12 1 1 4.107527 559.182796 71417.095009 4666.486285 19129.876586
2 0 2 0.286652 636.625821 69867.031199 4438.563836 5584.963443
13 1 2 4.406926 591.627706 71765.473616 4764.868233 19404.746082
3 0 3 0.323849 628.968201 69483.620639 4300.498560 5833.240296
14 1 3 4.628521 593.862676 70230.702943 4540.397929 19220.221603
4 0 4 0.522919 642.849819 69817.025081 4207.398307 6036.797102
15 1 4 4.799127 590.748908 71419.363512 4479.799450 20204.005841
5 0 5 0.845201 650.050862 70158.665028 4063.709107 6532.574802
16 1 5 4.693291 613.738019 69812.078978 4195.175035 18649.037444
6 0 6 0.901042 650.798828 69082.822538 3901.290777 6422.289949
17 1 6 4.567164 607.253731 70985.887712 4050.556868 18146.229257
7 0 7 1.265528 667.043478 70846.610828 3853.235682 6907.015686
18 1 7 5.000000 638.050000 69334.110872 3876.485605 18873.024796
8 0 8 1.615970 671.064639 71418.159414 3708.359463 7449.145197
19 1 8 5.000000 676.250000 68301.588226 3575.121841 17048.861106
9 0 9 1.697674 666.906977 74008.684770 3765.281520 7608.307502
10 0 10 2.545455 710.727273 66387.171349 3042.684203 9006.955532

I used boxplots to visualize the difference between fico scores for the two default values. The quartile values for defaulters are lower than those of repayers, but these boxplots have considerable overlap. FICO score should be considered when predicting default likelihood, but it has a lower correlation than I expected.

In [21]:
fig = px.box(
    loan_df,
    x = 'fico_score',
    color = 'default',
    title = 'FICO Score by Default Group',
    template = 'plotly_white',
    category_orders = {'default': [0, 1]}
)

fig.show()

The barplot below visualizes the proportion of defaulters for each credit range group. I notice that a greater proportion of borrowers with Poor credit defaulted on their loan, and that the proportion of defaulters decreases as credit scores improve.

In [23]:
#List storing the five credit range values
credit_range = ['Poor', 'Fair', 'Good', 'Very Good', 'Exceptional']

#Assigns each borrower a credit range value based on their fico score
loan_df['credit_range'] = np.select(
    [
        loan_df['fico_score'].between(300, 579),
        loan_df['fico_score'].between(580, 669),
        loan_df['fico_score'].between(670, 739),
        loan_df['fico_score'].between(740, 799),
        loan_df['fico_score'].between(800, 850)
    ],
    credit_range
)

#Calculates the proportion of borrowers who defaulted for each credit range value
credit_range_proportions = loan_df.groupby('credit_range')['default'].value_counts(normalize = True).reset_index()

#Plots grouped bar charts for each credit range value showing the proportion of borrowers in that group who defaulted
fig = px.bar(credit_range_proportions, x = 'credit_range', y = 'proportion', color = 'default', title = 'Credit Range Proportion by Default Group',
             category_orders = {'credit_range': credit_range}, barmode = 'group', template = 'plotly_white')
fig.show()

#Converts the categorical column to a factor for use in training predictive models
loan_df['credit_range'] = pd.factorize(loan_df['credit_range'])[0]

#Reorders the columns to keep default as the last column in the dataframe
col_reorder = list(loan_df.columns[:-2]) + [loan_df.columns[-1], loan_df.columns[-2]]
loan_df = loan_df[col_reorder]

This correlation matrix summarizes the findings from the above analysis. credit_lines_outstanding and total_debt_outstanding have strong positive correlation with default likelihood. years_employed and fico_score are negatively correlated with default, while the loan amount and income both have low correlation with default.

In [25]:
fig = px.imshow(
    loan_df.iloc[:, 1:].corr(),
    template = 'plotly_white'
)

fig.show()

I will use scikit-learn to train the machine learning models. My approach for model selection will be similar to scikit-learn's Classifier comparison. This task is classification because the feature columns are used to determine each borrowers default value: 0 for repayers and 1 for defaulters. I will use a for-loop to train multiple models - Decision Tree, Naive Bayes, K-Nearest Neighbors, Neural Network, Random Forest, and Gradient Boosting - in order to compare their accuracy and training time. To account for potential overfitting, I will use five-fold cross validation and calculate accuracy as the mean accuracy of the five models.

In [27]:
#Features are all columns except the target column (default) and customer_id, which is unique to each borrower
features = loan_df.columns.tolist()
features.remove('default')
features.remove('customer_id')

#Models in order: Decision Tree, Naive Bayes, K-Nearest Neighbors (K=3), Neural Network, Random Forest, Gradient Boosting
models = [
    DecisionTreeClassifier(),
    GaussianNB(),
    KNeighborsClassifier(n_neighbors=3),
    MLPClassifier(solver='adam', alpha=1e-5, hidden_layer_sizes=(5, 5), max_iter = 150, random_state=26),
    RandomForestClassifier(n_estimators=50, max_features=1, random_state=26),
    GradientBoostingClassifier(random_state=26)
]

#Stores model names, accuracy, and training time for output purposes
model_name = ['Decision Tree', 'Naive Bayes', 'K Nearest Neighbors', 'Neural Network', 'Random Forest', 'Gradient Boosting']
model_accuracy = []
training_time = []

#Calculates training time as the start time - time taken to calculate the cross-val score
start = datetime.now()

for model in models:
    #Calculates accuracy of 5-fold cross validation
    avg_cross_val_score = cross_val_score(model, loan_df[features], loan_df['default'], cv = 5).mean()
    model_accuracy.append(round(avg_cross_val_score, 5))
    #Calculates training time as the start time - time taken to calculate the cross-val score
    training_time.append(datetime.now() - start)
    start = datetime.now()

#Outputs the model data, organized with tabulate
print(tabulate([model_name, model_accuracy, training_time]))

--------------  --------------  -------------------  --------------  --------------  -----------------
Decision Tree   Naive Bayes     K Nearest Neighbors  Neural Network  Random Forest   Gradient Boosting
0.9954          0.9694          0.9791               0.9788          0.9929          0.9962
0:00:00.087078  0:00:00.023020  0:00:00.481423       0:00:06.091359  0:00:01.082952  0:00:05.655976
--------------  --------------  -------------------  --------------  --------------  -----------------

The Gradient Boosting model reported the highest accuracy. Despite this, I would recommend the Decision Tree model, as it produced only a slightly lower accuracy with substantially less training time needed. I will use this model to predict the probability of default for each borrower. Using the formula expected_loss = default_probability * loan_amount * (1 - recovery_rate), I will calculate the expected loss on each loan.

In [29]:
#Sets the recovery rate to the given value
recovery_rate = 0.1

#Splits the dataset into training and testing (20% for testing)
x_train, x_test, y_train, y_test = train_test_split(loan_df[features], loan_df['default'], test_size = 0.2, random_state = 26)

#Trains a Decision Tree Classifier using the training data
tree_model = DecisionTreeClassifier()
tree_model.fit(x_train.values, y_train.values)

#Calculates model accuracy to ensure the result matches the cross_val_score
accuracy = tree_model.score(x_test.values, y_test.values)
print('Model Accuracy:', accuracy)

#Calculates the probability of each borrower belonging to either default class (0 for repay, 1 for default)
default_probability = tree_model.predict_proba(loan_df[features].values)

#Retrieves the probability of each borrower defaulting from the predict_proba results
loan_df['default_probability'] = [i[1] for i in default_probability]
#Calculates expected loss as default_probability * loan_amt_outstanding * (1 - recovery_rate)
loan_df['expected_loss'] = loan_df['default_probability'] * loan_df['loan_amt_outstanding'] * (1 - recovery_rate)

#Outputs the result
loan_df[['customer_id', 'loan_amt_outstanding', 'default_probability', 'expected_loss']]

Model Accuracy: 0.995
Out[29]:
customer_id loan_amt_outstanding default_probability expected_loss
0 8153374 5221.545193 0.0 0.000000
1 7442532 1958.928726 1.0 1763.035853
2 2256073 3363.009259 0.0 0.000000
3 4885975 4766.648001 0.0 0.000000
4 4700614 1345.827718 0.0 0.000000
... ... ... ... ...
9995 3972488 3033.647103 0.0 0.000000
9996 6184073 4146.239304 0.0 0.000000
9997 6694516 3088.223727 0.0 0.000000
9998 3942961 3288.901666 0.0 0.000000
9999 5533570 1917.652480 0.0 0.000000

10000 rows × 4 columns

Putting it all together, I will use the probability that each borrower repays their loan and a recovery rate of 10% to calculate the expected loss on each borrower's loan. The code for this function is below:

In [36]:
#Function parameters are all model features + recovery_rate
def calculate_expected_loss(credit_lines_outstanding, loan_amt_outstanding, total_debt_outstanding, income, years_employed, fico_score, credit_range, recovery_rate):
    #Creates numpy array for loan data
    loan_data = np.array([credit_lines_outstanding, loan_amt_outstanding, total_debt_outstanding, income, years_employed, fico_score, credit_range])
    #Calculates the default probability using the decision tree model trained above
    #predict_proba requires the data to be reshaped when predicting probability for a single observation/row
    default_probability = tree_model.predict_proba(loan_data.reshape(1, -1))[0][1]
    #Calculates and returns expected loss
    expected_loss = default_probability * loan_amt_outstanding * (1 - recovery_rate)
    return round(expected_loss, 2)

#Tests the function using the second row of the dataset, where expected_loss > 0
borrower_data = list(loan_df.iloc[1, 1:-3])
calculate_expected_loss(*borrower_data, 0.1)
Out[36]:
1763.04
